5) Navigation keys
Control of input bar in edit and input mode or control of focus bar.
6) Soft key bar
Displays functions that can be called up by the soft keys.
7) Function keys
Are assigned the various functions displayed on the bottom of the screen.
1.4 FIXED KEYS
[User]: User key can be defined. It can be defined from the “Function” menu.
[FNC]: Quick access to measurement-supporting functions.
[Menu]: Menu key, to access to Programs, Settings, EDM Settings, File
Management, Adjustment, Comm Parameters, Data Transfer, System
Information.
[PAGE]: Page key. Turn to next page if several pages are available.
[ESC]: Quit a dialog or the edit mode without saving the changes. Return to an
upper menu.
[ENT]: Confirm an input, and continue to the next input field.
1.5 TRIGGER KEY
The measurement trigger key has three settings (All, DIST, OFF), which can be
defined in Settings.
1.6 SOFT KEYS
The measurement data is displayed in the several upper lines of the display,
while a selection of commands and functions are at the bottom of the screen,
which can be chosen by pressing corresponding function keys from F1 to F4.
