Sanding STS-752RC User Manual

129
8. DATA TRANSFER
With this special function measured data can be transferred via the serial
interface to receiver (e.g. a data collector) or USB interface to a PC. Using this
type of transfer the success of the transfer is not checked.
Job: Selection of job from which data should be transferred.
Data: Select the data range to be transferred (measurements, fixed points)
Transfer: COM port or USB port
Format: Select output format. GSI is the fixed setting.
STEPS
DISPLAY
In Page 2/2 of Menu, press F3 to enter to
Data Transfer.
【Menu】 2/2 ▲
F1 Adjustment
(5)
F2 Comm Parameter
(6)
F3 Data Transfer
(7)
F4 System Information
(8)
F1
F2
F3
F4
Enter the job name or search the job by
pressing LIST to view all the jobs.
Choose the data type you want to
transfer.
Choose the transfer mode: COM or USB
【Send Data】
Job
:
DEFAULT
Data
:
MeasVal
Transfer
:
USB
LIST
SEND
Ensure the total station and the PC or
PDA connected. Then press SEND.
【Meas. Data Send】
Transfer: USB
A:\DEFAULT.RAW
Sending……
*
0
BACK
