7. COMMUNICATION SETTING
To communicate data between computer and instrument, you must set
communication parameters.
BAUD RATE:
The optional baud rates are as follows: 1200, 2400, 4800, 9600, 19200, 38400,
57600, and 115200 [BIT /SECOND].
DATA BITS:
7 Data will be transmitted by 7 bit. As setting Parity check, it is set as 7 bit
automatically
8 Data will be transmitted by 8 bit. The parity is set as none automatically.
PARITY:
Even Even check
Odd Odd check
None None verify (If set data bit is 8 data bit)
END MARK:
CR/LF Carriage returns and line feed
CR Carriage returns
STOP BIT: 1
