125
For example: import HZ Alignment
STEPS
DISPLAY
Press F2 to enter to Data Import
【File Management】 3/3 ▲
F1 Data Output
(8)
F2 Data Import
(9)
F3 USB Send Data
(10)
F4 USB Receive
(11)
F1
F2
Press F3 to import the HZ Alignment data
to the internal memory from an SD card.
Enter the file name to contain the HZ
Alignment data or press LIST to select
the TXT file in the SD card. Press OK
【Data Import】
F1 Job data
(1)
F2 Code
(2)
F3 HZ Alignment
(3)
F4 VT Alignment
(4)
F1
F2
F3
F4
【Import file】
File name
:
SANDING
Time
:
2010.10.20
Time
:
12:00:00
LIST
OK
Start importing the HZ Alignment data to
SANDING.TXT in the SD card.
【HZ Alignment data】
From B:\SANDING.TXT
To A:\Road.HAL
*
1
BACK
* All the HZ Alignment data stored in the Road.HAL file.
6.9 USB SEND DATA/USB RECEIVE
Before transferring data through the USB cable, please ensure the PC has been
installed the miniUSB cable driver.
The transferred data through the USB cable can be job data, code, HZ alignment
