15
③When the measurement mode is changed, the battery power would not
immediately show the actual status. The battery power indicating system shows
the general status but not the instantaneous change of battery power.
Battery Recharging Cautions:
☆ Battery should be recharged only with the original charger.
☆ Remove the on-board battery from instrument and connect it to battery charger.
When the indicator lamp on the battery charger is flashing in red, the charging is
in progress. When charging is complete (indicator lamp turns green), disconnect
the charger from its power source.
☆ The charger has built-in circuitry for protection from overcharging. However, do
not leave the charger plugged into the power outlet after recharging is completed.
☆ Be sure to recharge the battery at a temperature from 0° to ±45°C. Recharging
may be abnormal beyond the specified temperature range .
☆ When the indicator lamp does not flash after connecting the battery and charger,
either the battery or the charger might be damaged. Please contact specialists for
repairing.
☆ Rechargeable battery can be repeatedly recharged 300 to 500 times. Complete
discharge of the battery may shorten its service life.
☆ In order to get the maximum service life, be sure to recharge it at least once a
month.
Battery Removal Cautions
：
☆ Before removing the battery from the instrument, make sure that the power is
turned off. Otherwise, the instrument may be damaged.
2.4 REFLECTOR PRISMS
When measuring distance, a reflecting system needs to be placed at the target
place. A reflector system consists with single prism or triple prisms, which can be
mounted on a tribrach or a prism pole. Reflector system can be self-configured
by users according to the work requirement.
