[APPENDIX-A] CALCULATING ROAD ALIGNMENT
The road alignment stake-out program can stake out the alignment elements
including straight, arc and transition curve.
NOTE:
1) Road alignment data can be uploaded from computer or can be entered
manually.
2) Road alignment data is managed by chainage.
1. ROAD ALIGNMENT ELEMENTS
There are two ways to enter the alignment elements:
1) Download from PC.
2) Manually entered on the STS-750RC series.
How to enter the alignment data is explained below:
Radius, Length of Transition Curve
NOTE: When downloading from computer or selecting PT option, you do not
have to calculate the Parameter.
Example:
To enter the following data select DEF AL of ROADS in PROG menu:
Chainage 0
N 1100.000
To Next Page
