Sanding STS-752RC User Manual

117
STEPS
DISPLAY
Choose the point you want to delete and
press DELETE.
【View Known Pt】
Job
:
A:\SANDING.PTS
PtID
:
1
X/N
:
0.000 m
Y/E
:
0.000 m
H/Z
:
0.000 m
SEARCH
DELETE
ADD
EDIT
Press OK to confirm to delete.
Or press CANCEL to cancel to delete.
【View Known Pt】
Delete data?
Deleted data No Revert!
CANCEL
OK
6.3 MEASUREMENT DATA
Measurement data available in internal memory can be searched and displayed.
Part of them can be deleted.
6.3.1 Viewing Measurement Data
Viewing measurement data is based on the unit of measurement station in
selected job. User may view one or all points (“*”) on a measurement station in a
certain job; or a certain PtID or all measurement data of all measurement stations
(“*”) in internal memory.
6.3.1.1 Viewing All Measurement Points in Job
Confirm the searching scope first: they may be all points of one measurement
station in a certain job；Or all points of all measurement stations (“*”) (i.e. all
measurement data in this job). Here, take viewing all measurement data in job as
an example.
