Sanding STS-752RC - START SURVEY

24
STEPS
DISPLAY
Press GRID.
【EDM Settings】
EDM Mode
:
Fine [r]
Reflect
:
Prism
Prism
-30.0 mm
ATMOS
GRID
SET.
↓
Input the scale and Ht.a.MSL.
Press SET. to save the change.
【Grid Factor】
Scale
:
1.000000
Ht.a.MSL
:
0.0 m
Grid
:
1.000000
BACK
0SET
SET.
3.2.4 Viewing Signal of Distance Measurement
This function displays the intensity of returned light signal (signal intensity) being
received by the total station, step length 1%. Once reflected light from the prism
is received, the total station will make beeping sound and show the laser intensity
which is expressed by %.
STEPS
DISPALY
Press ↓ to turn to next page of the
function key bar.
Press SIGNAL.
【EDM Settings】
EDM Mode
:
Fine [r]
Reflect
:
Prism
Prism
:
-30.0 mm
SIGNAL
MulCon
│←
Shows the intensity of the reflected laser.
【EDM Signal】
EDMType: RL
60%
BACK
