Sanding STS-752RC - Page 35

34
Tilt Crn.
(Tilt
Correction)
OFF
1-axis
2-axis
OFF: Tilt compensation is switched off.
1-axis: V-angle relate to the plumb line.
2-axis: V-angle refer to the plummet line and the
Hz-directions are corrected by the standing axis tilt.
The compensator setting remains active even after
the instrument is switched off.
Coll Crn.
(Collimation
Correction)
ON
OFF
ON : HZ Collimation is switched on.
OFF: HZ Collimation is switched off.
If the function “Coll Crn.” is active, each measured
horizontal angle is corrected.
For normal operation, the Hz Collimation remains
switched on.
SectorBeep
ON
OFF
ON: Sector Beep sounds at right angles (0°, 90°,
180°, 270°, or 0gon, 100gon, 200gon, 300gon)
OFF: Sector Beep is switched off.
Beep
ON
OFF
The beep is an acoustic signal after each key stroke.
ON: Beep switched on.
OFF: Beep switched off.
HZ <=>
Right Ang
Left Ang
Hz Increment Direction:
Right Ang: Set right Hz for “clockwise direction
measurement”.
Left Ang: Set left Hz for “Counter-clockwise direction
measurement”. “Counter-clockwise” directions are
only displayed but saved as “clockwise direction”.
Face Ⅰ Def.
VK-Left
VK- Right
Defines the telescope face Ⅰ in relation to the
position of the V circle.
Data Output
Intern
RS232
Intern: All data is recorded in internal memory.
RS232: Data is recorded via the serial interface. A
data storage device must be connected.
Auto - OFF
ON
OFF
ON: The instrument is switched off after 20 minutes
without any action (= no key pressed; V and HZ angle
deviation <3’/+600cc).
OFF: The instrument is switched on permanently.
Battery discharges quicker.
Min Reading
The displayed angle format can be selected in three
steps.
For 360° ′ ″: 0°00′01″/0°00′05″/0°00′10″
For 360°: 0.0001°/0.005°/0.0010°
For gon: 0.0001gon/0.0005gon/0.0010gon
For mil: 0.01mil/0.05mil/0.10mil
