Sanyo PLC-HP7000L Service Manual

-108-
Mechanical Parts List
KY2-HP7000L00
PACKING MATERIALS
610 357 0594 CARTON CASE-KY2AL
610 331 3016 CASE ACCESSORY-MZ7A
610 335 0479 CUSHION SPACER-MZ7A
610 334 9275 CUSHION L-KC3A
610 334 9374 CUSHION R-KC3A
645 096 4015 POLY BAG-0750X0600*NC*R8P
ACCESSORIES
OWNER’S SMANUAL
610 357 5520 CD-ROM,OWNERS MANUAL-KY2AL
610 357 5551 SETUP INST MANUAL-KY2AL
REMOTE CONTROL
645 105 0809 ASSY,REMOCON MXDD(SYANAI)
! AC CORD
US 945 064 6363 CORD,POWER-3.0MK,US
EU 945 054 1156 CORD,POWER-3.0MK
UK 945 054 1149 CORD,POWER-3.138MK
BRA 645 102 6996 CORD,POWER-2.5MK,BRA
MISCELLANEOUS
945 073 4855 CABLE,INTERFACE VGA
645 093 1642 CABLE,INTERFACE VGA
645 104 2705 CABLE,INTERFACE VGA
652 002 9552 CABLE,INTERFACE VGA
610 339 2950 ASSY,COVER LENS GH-KC3AL
610 331 7601 ASSY,MOUNTING LENS W-MR3A
910 301 6659 ASSY,SPACER BF-MY8A
MECHANICAL PARTS
CABINET PARTS
C01 610 335 5092 COMPL,STAND LEG-KC3BL
C02 610 340 4158 BUTTON CONT-KR7AL
C03 610 357 0471 CABINET TOP-KY2AL
C04 610 334 1347 CABINET FRONT-KC3A
C05 610 334 1422 CABINET FRONT COVER F-KC3A
C06 610 340 6954 CABINET FRONT COVER T-KR7AL
C07 610 356 7969 CABINET BACK-KY2AL
C08 610 356 7983 CABINET BOTTOM-KY2AL
C09 610 340 6992 COVER FUSE-KR7AL
C10 610 340 6961 COVER HANDLE-KR7AL
C11 610 334 2054 COVER NON LENS-KC3AL
C12 610 334 3303 DEC INLAY LED-KC3A
C13 910 302 5613 DEC SHEET-M4JA
C14 610 356 7990 DEC AV SHEET-KY2AL
C15 610 334 2139 HOLDER STOPPER-KC3A
C16 610 340 6978 PANEL LMP-KR7AL
C17 610 340 6985 PANEL FILTER-KR7AL
C18 910 293 9973 SPACER LEG-MA8A
C19 910 298 8575 SPACER COVER NWMG-MA8BA
C20 910 298 8582 SPACER COVER SCREW NWMG-MA8BA
C21 610 334 2023 SPRING STOPPER-KC3A
C22 610 341 1903 STOPPER COVER TOP-KR7AL
CHASSIS PARTS
M01 610 342 9571 ASSY,BOX FILTER DOUBLE-KH7AL
M02 610 334 3501 COMPL,HOLDER LNS SHIFT-KC3A
(Inlcuding Key No. M02-1 to M02-4)
M02-1 910 306 6630 ASSY,PWB,LENS-BASE NET MR3A
M02-2 610 334 3891 ASSY,HOLDER MTR LNS-KC3A
M02-3 645 092 6600 UNIT,LENS,SHIFT-X
M02-4 645 092 6617 UNIT,LENS,SHIFT-Y
M03 610 334 3549 GEAR MOTOR-KC3A
M04 610 357 2833 HOLDER FILTER BASE-KY2AL
M05 610 336 9921 COMP,HOLDER SHAFT FILTER-KC3A
M06 910 313 6678 LATCH-P8FK
M07 610 334 4300 MTG HLD SHAFT FIL-KC3A
M08 610 340 5469 COMPL,MOUNTING SHUTTER-KR7AL
M09 610 334 3051 HOLDER POL IN A-KC3A
M10 610 334 2849 HOLDER FILTER COVER-KC3A
M11 610 334 2771 HOLDER FILTER-KC3A
M12 610 341 1484 HOLDER POL IN A-KR7AL
M13 610 356 8010 HOLDER POL IN-KY2AL
M14 610 356 8041 MTG DUCT TOP LCD-KY2AL
M15 610 356 8058 MTG DUCT BTM LCD-KY2AL
M16 610 356 8065 MTG DUCT TOP LMP-KY2AL
M17 610 356 8089 MTG DUCT BTM LMP-KY2AL
M18 610 341 1637 OPTICAL BASE TOP-KR7AL
M19 610 357 0587 OPTICAL LMP COVER UV-KY2AL
M20 610 341 4935 ASSY,COVER YE-KR7AL
SCREWS
S01 411 189 8600 SCR BIN 3X8
S02 312 069 8300 SPECIAL SCREW W
S03 411 189 7207 SCR S-TPG BIN 3X8
S04 411 189 6606 BOLT HEX-SCT 2.5X6
S05 312 074 7107 SPECIAL SCREW V
OPTICAL PARTS
L01 610 357 5421 COMPL,OPTICAL-KY2AL
(Inckuding Key No. L01-1 to L01-13)
L01-1 645 105 0236 PRISM(PBS)
L01-2 945 047 2856 LENS,CONDENSER(IN)
L01-3 945 047 2870 LENS,CONDENSER(R)
L01-4 945 047 2887 LENS,RELAY(IN)
L01-5 945 085 7844 LENS,CONDENSER (B)
L01-6 645 097 3109 LENS,CONDENSER (G)
L01-7 945 044 2576 MIRROR(R)
L01-8 945 047 7516 MIRROR(B)
L01-9 945 086 2992 MIRROR(W-COLD)
L01-10 645 105 0274 OPTICAL FILTER(LC-CS)
L01-11 645 093 0027 POLARIZED GLASS(IN/GB)
L01-12 945 047 2924 DICHROIC MIRROR (B)
L01-13 645 098 9360 DICHROIC MIRROR (G)
Type-L LCD Panel/Prism Assy
L02L 610 357 5438 ASSY,PNL/PSM L-KY2AL
(Includng Key No. L02L-1R to L02L-2B and LCD Panels)
L02L-1R 645 103 5943 OPTICAL FILTER (ICV)
L02L-1G 645 103 5950 OPTICAL FILTER (ICV)
L02L-1B 645 103 5943 OPTICAL FILTER (ICV)
L02L-2R 645 105 0625 POLARIZED GLASS(OUT/R)1
L02L-2G 645 105 0632 POLARIZED GLASS(OUT/G)1
L02L-2B 645 105 0656 POLARIZED GLASS(OUT/B)1
Type-R LCD Panel/Prism Assy
L02R 610 357 5445 ASSY,PNL/PSM R-KY2AL
(Includng Key No. L02R-1R to L02R-2B and LCD Panels)
Key No. Part No. Description
Key No. Part No. Description
Mechanical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.
