-75-
Chassis Description
SW1861
LAMP COVER-SW
IC301
SCALER
&
SYSTEM
CONTROL
<PW392>
IC3401
Ye
CONTROL
FPGA
<EP3C80F484>
LAMP
LP900
AC
SW905
THERMAL
PROTECTOR
A902
POWER
A901
LAMP
BALLAST
Q1861
Q7796
LB_PIC_UART
PF_FAN
PFC_SW_EX
PIC_LB_UART
LAMP_SWIN_EX
LAMP_SWIN
PFC_SW
IC3402
IC1853
IC1854
IC1875
COVER SW.
1
2
2 4
32 17
4
78
155
250
25
25
5 1 4
5 1 4
3 1
3 1
K10B
CN6A
CJ1
CJ2
K6C
K6A K6B
K8K K8B
24
3
182
POWER-ON:H
POWER-ON:H
MAIN
FAN
CONTROL
Lamp control stage
