Sanyo PLC-HP7000L Service Manual

-48-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
4 Noise Gain Level <NSFILTERY**> / <NSFILTERUV**> 0 - 255 100
49 Noise Reduction (time) NR L2 Parameter
0 Noise Pixel Range <NSRANGEY> / <NSRANGEUV> 0 - 2 1
1 Noise Region 0 <NSREGIONY0> / <NSREGIONUV0> 0 - 1023 12
2 Noise Region 1 <NSREGIONY1> / <NSREGIONUV1> 0 - 1023 24
3 Noise Region 2 <NSREGIONY2> / <NSREGIONUV2> 0 - 1023 40
4 Noise Gain Level <NSFILTERY**> / <NSFILTERUV**> 0 - 255 100
50 2:2pull down setting
0 22Film Mode Sensitivity Film Detection Sensitivity <FILMSTVT22> 1 - 5 4
1 22Film Mode Threshold Low <FILMTHRD22A> 0 - 1023 80
2 22Film Mode Threshold High <FILMTHRD22B> 0 - 1023 120
3 Video Motion Window Start X <VOFSTARX> 0 - 255 10
4 Video Motion Window Stop X <VOFSTOPX> 0 - 255 10
5 Video Motion Window Start Y <VOFSTARY> 0 - 255 10
6 Video Motion Window Stop Y <VOFSTOPY> 0 - 255 10
51 2:3pull down setting
0 Global Motion Sensitivity Film Detection Sensitivity <FILMSTVT23> 1 - 5 4
1 Video Motion Sensitivity Film Detection Sensitivity <VOFSTVT> 1 - 5 4
2 Video Motion Threshold Low <VOFTHRDA> 0 - 1023 120
3 Video Motion Threshold High <VOFTHRDB> 0 - 1023 180
4 Global Motion 23Film Threshold <FILMTHRD23> 0 - 1023 100
5 Global Motion Window Start X <GMDSTARX> 0 - 255 10
6 Global Motion Window Stop X <GMDSTOPX> 0 - 255 10
7 Global Motion Window Start Y <GMDSTARY> 0 - 255 10
8 Global Motion Window Stop Y <GMDSTOPY> 0 - 255 10
55 LTI / CTI
0 Video Enhancement Enable VEHEN 0 - 1 1
1 DLTI Gain DLTIGAIN 0 - 15 3
2 DLTI Frequency DLTIFREQ 0 - 3 2
3 Bypass Anti-Alias Filter DTIBYPASSAAL 0 - 1 0
4 Lower DCTI Frequency LOWERDCTIFREQ 0 - 1 1
5 DCTI Gain DCTIGAIN 0 - 15 4
6 DCTI Frequency DCTIFREQ 0 - 3 0
7 Color Shift Limit COLORSHIFTLMT 0 - 3 3
60 Sub Image
0 Center Contrast
Group
Composite / S-Video / Component / Digital /D-RGB-Video
/AnalogRGB / RGB-Video / HDCP-PC /HDCP-AV /SCART/ PJ-
Net
Value = (Menu Value - Menu Center) x Alpha / 10 + Center
(Effective Range)
Contrast [Max] 1023 [Min] 0
Brightness [Max] 1023 [Min] 0
Color [Max] 1023 [Min] 0
Tint [Max] 180 [Min] 0
Sharpness [Max] 57 [Min] 0 (Dummy)
WB R/G/B [Max] 1023 [Min] 0
BB R/G/B [Max] 1023 [Min] 0
Fixed Sharpness Up/Down [Max] 37 [Min] 0
0 - 1023
534/534/578/492/492/534/
534/492/492/534/492
1 Center Brightness 0 - 1023
512/512/512/512/512/496
496/512/512/496/512
2 Center Color 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
3 Center Tint 0 - 180 90/90/90/90/90/90/ 90/90/90/90/90
4 Fixed Sharpness(Up Scaling) 0-37 5/5/5/5/5/5/ 5/5/5/5/5
5 Fixed Sharpness(Down Scaling) 0-37 8/8/8/8 /8/8/ 8 /8/8/8/8
6 Center Sharpness(No FPGA) 0-37 16/16/16/16/16/16/ 16/16/16/16/16
7 Center WB Red 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
8 Center WB Green 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
9 Center WB Blue 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
10 Center BB Red 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
11 Center BB Green 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
12 Center BB Blue 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
13 Alpha Contrast 0 - 1000 60/60/60/60/60/60/ 60/60/60/60/60
14 Alpha Brightness 0 - 1000 90/90/90/90/90/90/ 90/90/90/90/90
15 Alpha Color 0 - 1000
140/140/140/140/140/140
/140/140/140/140/140
16 Alpha Tint 0 - 1000 10/10/10/10/10/10/ 10/10/10/10/10
17 Alpha Sharpness 0 - 1000 10/10/10/10/10/10/ 10/10/10/10/10
18 Alpha WB Red 0 - 1000 40/40/40/40/40/40 / 40/40/40/40/40
19 Alpha WB Green 0 - 1000 40/40/40/40/40/40 / 40/40/40/40/40
20 Alpha WB Blue 0 - 1000 40/40/40/40/40/40/ 40/40/40/40/40
21 Alpha BB Red 0 - 1000 20 /20/20/20/20/20/ 20/20/20/20/20
