Part Names and Functions
qIndicators
wTop Cover
e Top Cover Release Button
rInfrared Remote Receiver (Front)
CAUTION
Hot air is exhausted from the exhaust
vent. Do not put heat-sensitive objects
near this side.
!2 Terminals and Connectors
!3 Infrared Remote Receiver (Back)
!4 Power Cord Connector
!5 Optional Parts Attachment
!6Side Controls
!7Hand Grip
t Projection Lens (optional)
yLight-Block Sheet
u Adjustable Feet
i Air Intake Vent
o Filter Cover
!0 Lamp Cover
!1Exhaust Vent
u
e
r t
Front
!0o
q
w
y i
u
