33
Press the FREEZE button on the remote control to freeze
the picture on the screen. To cancel the FREEZE function,
press the FREEZE button again or press any other button.
FREEZE button
FILTER button
Press and hold the FILTER button for more than five seconds
to operate electrically operated filter to replace the filter.
KEYSTONE button
Reduce the upper width with
Point e button.
Reduce the lower width
with Point d button.
Reduce the left part with
Point 7 button.
Reduce the right part with
Point 8 button.
• The white arrows indicate that there is no correction.
• A red arrow indicates the direction of correction.
• An arrow disappears at the maximum correction.
• If you press the KEYSTONE button on the remote
control again while the Keystone dialog box is being
displayed, the keystone adjustment will be canceled.
• The adjustable range can be limited depending on the
input signal.
• “Keystone” disappears after 10 seconds.
Remote Control
POINTER button
FILTER button
✔Note:
•See the previous page for the
descriptionofotherbuttons.
MOUSE
POINTER
button
Press the KEYSTONE button on the remote control. The
“Keystone” appears on the screen.
Use the Point ed7 8 buttons to correct keystone
distortion. The keystone adjustment can be stored (pp.44,
48).
Basic Operation
✔Note:
•Thefiltercannotberewound.
•Whenthefilterisreplaced,thetotalaccumulatedtimeofthefilter
useisautomaticallysetto0.
KEYSTONE
button
FREEZE button
P-TIMER button
Move the pointer on the screen with this button.
MOUSE POINTER button
POINTER button
Press POINTER button on the remote control to display the
Pointer on the screen.
P-Timer display
Press the P-TIMER button on the remote control. The Timer
display “00 : 00” appears on the screen and starts to count
time (00 : 00–59 : 59).
To stop the P-TIMER, press the P-TIMER button.
To cancel the P-TIMER, press the P-TIMER button again.
P-TIMER button
To Next Page
