14
q STAND-BY button
Turn the projector off (p.27).
r ON button
Turn the projector on (p.26).
yINPUT button
Select a signal (pp.35–37).
iSCREEN button
Select the screen size (p.32).
r
Remote Control
!0
!4
q
!4 L- CLICK button
Act as the left mouse button for wireless mouse
operation (p.34).
e SIGNAL EMISSION indicator
Light red while a signal is being sent from the
remote control to the projector.
o POINT ed 7 8 ( VOLUME + / – , MUTE) buttons
– Select an item or adjust the value in the On-
Screen Menu (p.28).
– Pan the image in Digital zoom + mode (p.44).
– Adjust the volume level (with Point 7 8 buttons)
or mute the sound (with Point d button.) (p.31).
To ensure safe operation, observe the following
precautions:
– Do not bend, drop, or expose the remote control to
moisture or heat.
– For cleaning, use a soft dry cloth. Do not apply
benzene, thinner, splay, or any other chemical
materials.
e
w WIRED REMOTE jack
Connect the remote control cable (not supplied) to
this jack when using as a wired remote control.
!1 SELECT button
– Execute the selected item (p.28).
– Expand or compress the image in the Digital
zoom mode (p.44).
w
u MENU button
Open or close the On-Screen Menu (p.28).
!2
!0 MOUSE POINTER button
Move a pointer of the projector or a pointer for
wireless mouse operation (p.34).
Part Names and Functions
tAUTO PC button
Automatically adjust the computer image to its
optimum setting (pp.32, 39).
t
!3
y
u
i
o
!1
!3INFO. button
Display the input source information (p.32).
!2
SHUTTER button
Close and open up the built-in shutter (p.30).
To Next Page
