Sanyo PLC-XP200L User Manual

54
Change the Logo PIN code lock setting
After a correct Logo PIN code is
entered, the following dialog box
appears.
Use the Point 7 8 buttons to switch On/Off,
This function prevents an unauthorized person from changing the
screen logo.
Off . . . . The screen logo can be changed freely from the Logo
Menu.
On . . . . The screen logo cannot be changed without a Logo
PIN code.
If you want to change the Logo PIN code lock setting, press the
SELECT button and the Logo PIN code dialog box appears. Enter
a Logo PIN code by following the steps below. The initial Logo PIN
code is set to “4321” at the factory.
Logo PIN code lock
Enter a Logo PIN code
Change the Logo PIN code
Logo PIN code can be changed to your desired four-digit number.
Press the Point d button to select “Logo PIN code change” and
then press the SELECT button. The New Logo PIN code input
dialog box appears. Set a new Logo PIN code.
Be sure to note the new Logo PIN code and keep it on hand. If
you lost the number, you could no longer change the Logo PIN
code setting. For details on PIN code setting, refer to “PIN code
lock” on pages 57–58.
Logo PIN Code Lock
Enter a Logo PIN code
Use the Point 7 8 buttons to switch On/Off, and then press the
Point d button to move the pointer to “Quit.” Press the SELECT
button to close the dialog box.
Change the Logo PIN code lock setting
CAUTION:
WHEN YOU HAVE CHANGED THE LOGO PIN
CODE, WRITE DOWN THE NEW PIN CODE
IN COLUMN OF THE LOGO PIN CODE NO.
MEMO ON PAGE 83, AND KEEP IT SECURELY.
SHOULD THE LOGO PIN CODE BE LOST OR
FORGOTTEN, THE LOGO PIN CODE SETTING
CAN NO LONGER BE CHANGED.
Change the Logo PIN code
Use the Point ed buttons on the side control or Number buttons
on the remote control to enter a number.
When using side control
Use the Point ed buttons on the side control to select a number.
Press the Point 8 button to fix the number and move the red
frame pointer to the next box. The number changes to “✳.”
Repeat this step to complete entering a four-digit number. After
entering the four-digit number, move the pointer to “Set.” Press
the SELECT button so that you can change the Logo PIN code
lock setting.
When using remote control
Press the Number buttons on the remote control to enter a
number (p.15). When you complete entering a four-digit number,
the pointer moves to “Set.” Press the SELECT button so that you
can change the Logo PIN code lock setting.
If you fixed an incorrect number, use the Point 7 button to move
the pointer to the number you want to correct, and then enter the
correct number.
If you entered an incorrect PIN code, “Logo PIN code” and the
number (✳✳✳✳) will turn red for a moment. Enter the correct PIN
code all over again.
Setting

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
