Sanyo PLC-XP200L User Manual

79
ON-SCREEN
DISPLAY
RESOLUTION
H-Freq.
(kHz)
V-Freq.(Hz)
D-VGA 640x480 31.470 59.940
D-480p 720x480 31.470 59.880
D-575p 720x575 31.250 50.000
D-SVGA 800x600 37.879 60.320
D-XGA 1024x768 43.363 60.000
D-WXGA 1 1366x768 48.360 60.000
D-WXGA 2 1360x768 47.700 60.000
D-WXGA 3 1376x768 48.360 60.000
D-WXGA 4 1360x768 56.160 72.000
D-WXGA 5 1366x768 46.500 50.000
D-WXGA 6 1280x768 47.776 59.870
D-WXGA 7 1280x768 60.289 74.893
D-WXGA 9 1280x800 49.600 60.050
D-WXGA 10 1280x800 41.200 50.000
ON-SCREEN
DISPLAY
RESOLUTION
H-Freq.
(kHz)
V-Freq.(Hz)
D-WXGA 11 1280x800 49.702 59.810
D-SXGA 2 1280x1024 60.276 58.069
D-SXGA 3 1280x1024 31.650 29.800
D-WXGA+ 1 1440x900 55.935 59.887
D-720p 1280x720 45.000 60.000
D-720p 1280x720 37.500 50.000
D-1035i
1920x1035
(Interlace)
33.750 60.000
D-1080i
1920x1080
(Interlace)
33.750 60.000
1920x1080
(Interlace)
28.125 50.000
D-1080psf/30 1920x1080 33.750 60.000
D-1080psf/25 1920x1080 28.125 50.000
D-1080psf/24 1920x1080 27.000 48.000
When an input signal is digital from the DVI terminal, refer to the chart below.
Appendix
✔Note:
 •Dependingontheconditionofsignalsandthetypeandlengthofcables,thesesignalsmaynotbeproperly
viewed.
 •Specificationsaresubjecttochangewithoutnotice.
This symbol on the nameplate
means the product is Listed
by Underwriters Laboratories
Inc. It is designed and
manufactured to meet rigid
U.L. safety standards against
risk of fire, casualty, and
electrical hazards.
The CE Mark is a Directive
conformity mark of the European
Community (EC).
Pixelworks ICs used.

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
