103
Operating the Scale
Printout for Differential Weighing
Generating Configured Printouts
Automatically
The configured backweighing printout
is generated automatically after
backweighing, if one of the following
settings is selected under Setup:
Application 1: Differential weighing:
Generate printout:
Automatic after
backweighing
Auto after init.weigh +
backweigh
Auto after tare, init.
+backweigh.
Generating Configured Printouts
Manually
The configured individual printout is
generated when the p key is
pressed while there is a tare, initial or
backweight on the scale or when D
is pressed to toggle applications.
You can generate the configured
printout manually after backweighing
if you press the p key while the
display page for the results is shown.
To generate the configured statistics
printout, press the p key
– when the display page for statistics
is shown,
– when the samples with a desired
number of backweighing
operations is selected (for
example, statistics on all samples
with 2 backweighing operations)
The following printout is generated:
Configured Backweighing Printout (Example)
--------------------- Dotted line
16.11.1999 14:55:12 Date/Time
Lot CH12345 Lot ID
Sample 14 Sample number
ID CX88 Sample ID
T1 + 23.45 g Tare weighing (with PT1 selected)
N1 + 125.57 g Initial weight
R (3)+ 103.68 g Backweight (residue as weight)
R + 82.57 % Residue in percent
D - 21.88 g Loss as a weight
D - 17.43 % Loss in percent
Fact + 1.10345 Calculation factor
D-Res - 24.15 o Calculated loss
Ratio1 + 21.11 % Ratio 1
Ratio2 + 121.11 % Ratio 2
--------------------- Dotted line
