191
Overview
RS-485 data interface (must be installed at the Sartorius
Fast Factory or by a Sartorius service technician)
for FC…BBE/CCE models: TTY/10 mA YDO01F-X
for FC…BBE/CCE models: RS-485 YDO02F-X
for FC…EDE models RS-485 YDO03FC-X
for FC…EDE models TTY/10 mA YDO04FC-X
for FCA models: TTY/10 mA YDO01FT-X
for FCA models: RS-485 YDO02FT-X
Cable for connecting weighing platform to separate
display and control unit (length: 2.70 m ≈ 9 ft.) Ask for
for FC…EDE models information
for models with a weighing capacity ≤12 kg YCC01-19M3
Front-mounted tiltable display and control unit YDH01F
Wrap-around load plate YLP01
for models FC6CCE-SX, FC12CCE-SX, FC12CCE-I X
Hook for under-scale weighing for FC-EDE models 69EA0040
Calibration weights Ask for
for all FB scales, extensive assortment, optionally available information
with officially recognized DKD certificate
Extension cable YCC01-01ISM6
12-pin round male connector/
12-pin round female connector (6 m; ≈ 20 ft.)
Interface cable YCC01-03ISM5
for connecting a PC to the YDI03-Z, YDI01-Z Zener barrier
Interface cable YCC01-0019M3
for directly interfacing the scale to the YDP03-0CE
data printer (via Zener barrier)
Adapter cable YCC01-0016M3
From round male connector to RS232-D-Submini
female interface connector; for directly connecting
Sartorius accessories to the scale (via Zener barrier)
Adapter cable, from 25-pin D-Submini 6965619
male connector to 9-contact D-Submini
female connector; length 0.25 m (≈ .8 ft.)
Tiltable display and control unit retainer for wall mounting
(stainless steel) for FCA display and control units YDH01F
Adapter plate for fastening the FCA display and control
unit to the floor stand YAS01FT-X
Floor stand (stainless steel), height: 1.1m (approx. 3.5 ft) YDH03IS
for FCA display and control units
(adapter plate YAS01FT-X required)
SartoConnect data transfer software for YSC01I
connecting your Sartorius scale to a PC running
the Windows 95, 98 or NT operating system.
For loading measurement data from the scale into any PC
for further processing (e.g., with Excel or Access)
Includes 9/12-pin cable for connecting the scale to the PC.
Sartorius Win Scale YSW03
Scale driver software for use under Windows 95/98/2000/NT.
Display scale readout on the PC monitor and provides secure
memory for storing data that is subject to legal control.
Configuration software (PC, DOS) YAD01IS
For storing and loading scale settings
Sartorius “NICE Label Express” YAD02IS
For creating customer-specific printouts
Profibus serial interface (must be connected outside
hazardous area/location using Zener barrier)
– for RS-232 interface YSPI3-232
– for RS-485 interface YSPI3-485
