189
Overview
Accessories (Options)
Product Order No.
Power supply (AC adapter) for use outside a hazardous
area/location
European version: YPS02-ZDR
GB version: YPS02-ZGR
! Install the cable so that it is protected from damage.
Connect the terminal of the housing to a terminal
for equipotential bonding (PE = protective earthing
or grounding conductor)
Power supply (AC adapter) for use within a hazardous
area/location
European version: YPS02-XDR
GB version: YPS02-ZGR
! Install the cable so that it is protected from damage.
Connect the terminal of the housing to a terminal
for equipotential bonding (PE = protective earthing
or grounding conductor)
Zener barrier for use outside a hazardous area/location
– 4 data lines YDI02-Z
– 4 data lines and 4 control lines YDI03-Z
– Connection in a bus system over RS485
(data cable not supplied) YDI01-Z
! Install the cable so that it is protected from damage.
Connect the terminal of the housing to a suitable
ground electrode (PE = protective earthing
or grounding conductor).
T-connector for hazardous areas/locations YTE02-X
! Install the cable so that it is protected from damage.
