Operating the Scale
Practical Example
Totalize counted pieces
Settings (changes in the factory settings required for this example):
Setup: App(lication parameters): Application 1: Counting
Setup: App(lication parameters): Application 2: Off
Setup: App(lication parameters): Application 3: Totalizing: Evaluated values: Net + calculated
Setup: App(lication parameters): Application 3: Totalizing: Evaluation mode, MR function: Final evaluation, display + print
Step Press key(s) Display/Output
(or follow instructions)
1. Turn on the scale and configure e
the settings as indicated above
2. Delete old totalization data,
if necessary c
3. Tare the scale t
4. Toggle to Application 1: Counting D
5. Place the displayed number of Place parts to be counted
parts on the scale (here: 10 pcs) on the scale
6. Initialize the Counting application
Start soft key
7. Remove the reference sample Unload the scale
quantity and toggle to Totalizing D
8. Place a number of parts on the Place parts on the scale
scale (here: 50 pcs)
