133
Operating the Scale
9. Store piece count M+ soft key
10. Unload the scale Remove parts from
the scale
11. Place another load of parts Place parts on the scale
on the scale (e.g., 29 pcs)
12. Add piece count to stored total
M+ soft key
13. Repeat steps 11 and 12
as required
14. Display final evaluation
MR soft key
(»Info« window) (here: 5
weighing operations;
total quantity: 165)
The o indicates which value is
displayed in the text line; you can
change this selection
15. Print final evaluation p
