Sartorius Factory Series User Manual

171
Operating the Scale
Cabling Diagram: Profibus
FC…….. –X…
with RS-232
port
PLC
Simatic S7
(Siemens)
FC…….. –X…
with RS-485
port
Hazardous area/location Safe area
Bus line
(not part of
equipment
supplied)
VF2464
YSPI3-232
YDI02- Z
YDI03-
Z
VF2465
YDI01-Z YSPI3-485
12-pin
round
9-pin
DSUB
Adapter for
Profibus DP
Barrier
9-pin.
DSUB
1,200 m max.
(please comply
with the specifications
given in the EC Type
Examination Certificate)
20 m
(please comply
with the specifications
given in the EC Type
Examination Certificate)
1)
1)
1)
1)
2)
2)
2)
3)
1: 14-pin connector; order no. 69Y03166
2: Junction box; order no. 72583
3: Sartonet cable; order no. 6906926 (specify length)
4: Order cable through our Fast Factory. Be sure to specify the length when ordering.
The total length incl. the cable between the scales and the barrier may not exceed 1,200 m max.
5: Order cable through our Fast Factory. Be sure to specify the length when ordering.
The total length incl. the cable between the scales and the barrier may not exceed 23 m max.
4)
5)
8
1
Up to 8 scales max.
FC…….. –X…
with RS-485
port
