Overview
Overview of the Scales
FC6CCE-HX(CE), FC2CCE-SX(CE), FC12CCE-SX(CE), FC12CCE-IXCE, FC6CCE-SX(CE)
“-CE” identifies the scale as verified for legal metrology in the EU*
Pos. Designation Spare Part Order No.
1 Display and control unit
2 Weighing pan/load plate 69 LP0007
3 Pan shield
(depends on type of model) 69 LP0008
4 Leveling foot 69 B20005
5 Menu access switch
6 Shock absorber 69 LP0010
7 Metrological ID label
(only on scales verified for legal metrology
in the EU)
8 Tare key
9 Function keys
10 Print key
11 Numeric keys
* including the Signatories of the Agreement
on the European Economic Area
Pos. Designation Spare Part Order No.
12 Shift key for entering letters
13 On/off key
14 Display
15 Lug for attaching an
antitheft locking device
16 Main grounding conductor
17 AC power socket
18 Data interface port
19 Level indicator
Not shown:
Dust cover for weighing platform 69 60FB02
Dust cover for display&control unit 69 60LP03
Caps and plugs for
covering ports (set) 69 B20009
