Sartorius Factory Series User Manual

181
Overview
Model FC64EDE-H, FC34EDE-H, FC16EDE-H,
FCA64EDE-HX FCA34EDE-HX FCA16EDE-HX
Readability g 0.1 0.1 0.1
Weighing capacity kg 64 34 16
Max. overload capacity kg 130 130 130
Tare range (subtractive) kg – 64 – 34 – 16
Electronically compensated preload kg 13 4 4
(without restricting weighing range)
Max. preload when starting kg ca. 45 ca. 21 ca. 19
calibration/adjustment (scale display
does not have to be zeroed)
Repeatability ≤±g 0.1 0.1 0.05
Linearity ≤±g 0.5 0.2 0.2
Sensitivity drift within +10 ... +30 °C ≤±/K 3 · 10
–6
2 · 10
–6
2 · 10
–6
Response time (average) s 1.5 1.5 1.5
External standard calibration weight kg 10 (F1) 10 (F1) 10 (F1)
(of at least accuracy class...)
Platform dimensions mm 300 x 400
Net weight, approx. kg 16.0
Dust and water protection rating
according to EN 60529 IP44 IP65 IP65
Model FC34EDE-PX, FC12EDE-PX, FC64EDE-SX,
FCA34EDE-PX FCA12EDE-HX FCA64EDE-SX
Readability g 0.1/0.2/0.5 0.1/0.2 1
Weighing capacity kg 8/16/34 6/12 64
Max. overload capacity kg 130 130 130
Tare range (subtractive) kg – 34 – 12 – 64
Electronically compensated preload kg 4 4 13
(without restricting weighing range)
Max. preload when starting kg ca. 21 ca. 10 ca. 45
calibration/adjustment (scale display
does not have to be zeroed)
Repeatability ≤±g 0.05/0.05/0.1 0.05/0.05 0.3
Linearity ≤±g 0.2 0.2 1
Sensitivity drift within +10 ... +30 °C ≤±/K 2 · 10
–6
2 · 10
–6
3 · 10
–6
Response time (average) s 1.5 1.5 1.5
External standard calibration weight kg 10 (F2) 10 (F1) 10 (F2)
(of at least accuracy class...)
Platform dimensions mm 300 x 400
Net weight, approx. kg 16.0
Dust and water protection rating
according to EN 60529 IP65
