Overview
Models Verified by the Manufacturer, with EC Type Approval
General Specifications
AC power source/power requirements AC adapter, 90 V AC (min.) to 264 V AC (max.)
Frequency 48 – 60 Hz
Allowable ambient temperature range 0…+40°C (273…313 K, 32°F…104°F)
Adaptation to ambient conditions By selection of 1 of 4 optimized filter levels
Display update 0.1 – 0.4
(depends on the filter level selected)
Power consumption 25 VA
Selectable weight units Grams, kilograms
Selectable application programs Mass unit conversion, counting, weighing in percent, animal weighing, calculation, density
determination, over/under checkweighing, time-controlled functions, totalizing, statistics,
2nd tare memory, identifiers
Built-in interface RS-232C
Format: 7-bit ASCII, 1 start bit,
1 or 2 stop bits
Parity: Space, odd, even
Transmission rates: 150 to 19,200 baud
Handshake: Software or hardware
Specifications of the Individual Models:
Model FC06BBE-SXCE FC6CCE-HXCE FC2CCE-S0CE
Type isoTEST in conjunction with BD BF
Accuracy class * KKK
Scale interval d* g 0.001 0.01 0.01
Max. weighing capacity* g 620 6,200 2,200
Verification scale interval e* g 0.01 0.1 0.1
Min. capacity* g 0.02 0.5 0.5
Max. overload capacity kg 3 25 10
Tare range (subtractive) ≤ 100% of the max. weighing capacity
Electronically compensated preload g 93 – 110
(without restricting weighing range)
Max. preload when starting g 110 5,200 1,300
calibration/adjustment
(scale must be zeroed)
Application range according to CD* g 0.02 – 620 0.5 – 6,200 0.5 – 2,200
Response time (average) s 1.5 1.5 1.5
Pan/load plate size mm Ø 130 218 x 200 218 x 200
Dimensions (W x D x H) mm 240x294x86 240x294x86 240x294x86
Net weight. approx. kg 7 8.4 7.3
Dust and water protection rating
according to EN 60529 IP 54 (protected against harmful dust deposits and splashes of water)
* CD = Council Directive 90/384/EEC on non-automatic weighing instruments used within the European Economic Area
