Appendix B Programmable Parameters
Table B-9 Setpoint Actions
Action type Action target
Label Description Range Description
rES.C Clear counter Cnt1 - Cnt8 Counter number
Clr.E Reset energy registers nonE n/a
Clr.d Reset extreme demands nonE n/a
Cl.tE Reset TOU energy nonE n/a
Cl.td Reset TOU demands nonE n/a
Clr.C Clear counters nonE n/a
Cl.LH Clear Min/Max registers nonE n/a
EU.LG Event logging OPEr = setpoint
operation
rELS = setpoint
release
AnY = either
transition
Setpoint transition
mode - type of events
that trigger logging
dt.LG Data logging LG01-LG16 Log number
LF.LG High-speed (32/16)
waveform logging
nonE n/a
HF.LG High-resolution (128/4)
waveform logging
nonE n/a
Table B-10 Reset/clear Functions
Access
Function Description Front-
panel
Commu-
nications
Clear total energy registers Resets total accumulating energy
registers
• •
Clear total extreme
demands
Resets total extreme
(minimum/maximum) demands
• •
Clear TOU energy registers Resets TOU accumulating energy
registers
• •
Clear TOU extreme
demands
Resets TOU extreme
(minimum/maximum) demands
• •
Clear pulse counters Resets all counters
• •
Clear Min/Max log Clears all real-time Min/Max log
registers
• •
Clear event log Clears the event log partition
•
Clear data log Clears one of 16 data log partitions
•
