34 CSP-204 ● CSP-208 ● CSP-104 ● CSP-108 SATEL
5. Using the and buttons, specify the options. The ON LEDs indicate that the
following options have been selected:
1 – confirmation of fire alarm transmission;
2 – confirmation of fault warning transmission.
6. Press the button to save the changes made.
10. Programming the delay time for inputs
1. Using the buttons , select the function 10 (see: Table 1, p. 29).
2. Press the button.
3. Press one of the buttons to select the input for which the delay time will be
programmed.
4. Press the button.
5. Using the buttons
,
specify the delay time (see: Table 4, p. 32).
6. Press the button to save the changes made.
11. Programming the sounder parameters
1. Using the buttons , select the function 11 (see: Table 1, p. 29).
2. Press the button.
3. Press the or button to select the sounder for which the operating mode will be
programmed.
4. Press the button.
5. Using the and buttons, specify the operating mode.
LED number
1 2
Sounder operating mode
alarm II
alarm I or II
alarm I (p) or II
Table 6. Presentation of the sounder operating mode using the LEDs
( - LED OFF; - LED ON).
6. Press the button to save the changes made.
12. Enabling / disabling routing outputs
1. Using the buttons , select the function 12 (see: Table 1, p. 29).
2. Press the button.
