SATEL GSM-X 33
Module – type and version of the module firmware.
Module key – a string of characters for identification of the module. You can enter up to 16
alphanumeric characters (digits, letters and special characters). You can use spaces, but
at least one character must be different from space. Do not program the same key for
different modules. Communication between the GX Soft program and the module is
possible if the keys in the program and the module are identical.
IMEI – individual identification number of the module GSM telephone.
ID – individual identification number for the purposes of communication through the SATEL
server (assigned automatically by the SATEL server).
7.8.1 SATEL server
Connect to GX Control – if this option is enabled, it is possible to establish connection
between the GX Control application and the module through the SATEL server.
Push notifications – if this option is enabled, the GX Control application can provide
information about events by means of push notifications.
Connect to GX Soft – if this option is enabled, it is possible to establish connection between
the GX Soft program and the module through the SATEL server.
Make sure that the SIM card tariff plan is suited to the requirements of communication
via the SATEL server (GPRS connection to the server is active at all times).
Channel – you can select a channel that will be used for communication between the module
and the SATEL server:
GPRS – GSM network.
GSM-X-ETH/GPRS – Ethernet network or GSM network. Ethernet network has priority.
GSM network is used if there is no communication over the Ethernet network.
GSM-X-ETH – Ethernet network.
Communication using the Ethernet network is possible if the GSM-X-ETH module is
installed.
7.8.2 Direct connection to GX Soft
Server address – address of the computer running the GX Soft program. It must be a public
address. You can enter the IP address or domain name.
Port – number of the TCP port used for direct communication between the module and the
computer with GX Soft program. You can enter values from 0 to 65535 (0=disabled).
Server address from SMS – if this option is enabled, the address of server, to which the
module is to connect, and the port number can be entered in the content of SMS message
initiating the connection. If the address is not entered, the module will connect to the
computer whose address has been programmed in the module.
SMS function – the function that is run on receiving the control message. The functions are
used to establish communication between the module and the GX Soft program:
Configuration over GPRS – SIM 1 – via GPRS using SIM1 card.
Configuration over GPRS – SIM 2 – via GPRS using SIM2 card
Configuration over Ethernet – via Ethernet network (when GSM-X-ETH module is
installed).
SMS command – control command which can be sent in SMS message to initiate
communication between the module and the GX Soft program. You can enter up to 16
alphanumeric characters except spaces (digits, letters and special characters).
The content of control commands must vary.
