6 Installation of Options
112
CL4NX/CL6NX Service Manual
3 Remove the screw 4, slide and lift to
remove the left housing cover
2.
Note
When removing the left housing cover, make sure that
the cover does not touch the PCB, causing the
components of the PCB to be deformed.
4 Remove the screws ( to remove the
cover
,, then remove three screws " to
remove the media holder plate
0.
7
6
Slide
& Lift
9
Slide
8
11
10
