6 Installation of Options
145
CL4NX/CL6NX Service Manual
23 Remove the screw  attaching the
sensor tension
.
24 Replace the sensor tension  with the
RFID sensor tension
 and attach it
using the screw
 .
Note
Do not mix up the sensor tension  and the
RFID sensor tension
 as they have the same
shape.
25 Attach the EXT PCB ; and tighten four
screws
.
26
27 28
30
29
