SATO FX3-LX Driver Manual

20
Installing the driver when connected via Bluetooth 1.3.3
Add the printer to the computer as a Bluetooth device (this is called pairing) and install the printer
driver on the computer. The procedure for pairing a Bluetooth device varies depending on your
computer environment. The following procedure is an example using Windows 10.
For details, refer to the user manual of your computer.
For details of the printer screen and operations, refer to "FX3-LX Operator Manual."
Pairing the printer with the computer
Start the computer. 1.
Power on the printer. 2.
Check the following settings on the printer's [Bluetooth] menu. 3.
 The [Enable] check box is selected
 Device name (default: SATO PRINTER_xxxxxxxxxxxx)
"xxxxxxxxxxxx" is a 12-digit alphanumeric value.
Note:
You can change the name by tapping the device name.
Click the arrow ([Show hidden icons]) ([a]) on the bottom-right of the computer desktop, 4.
right-click the Bluetooth icon ([b]), and select [Add a Bluetooth Device].

SATO FX3-LX Specifications

General

Cutter	Yes
Certification	EN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodes	AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID module	No
Maximum resolution	- DPI
Maximum print height	500 mm
Maximum printing width	80 mm
Battery voltage	14.4 V
AC input voltage	100 - 240 V
Battery capacity	1950 mAh
AC input frequency	50 / 60 Hz
Suitable for use in country/location	Europe
Sustainability certificates	ENERGY STAR
Display	LCD
Control type	Touch
Product color	White
Display diagonal	7 \
Display resolution	480 x 800 pixels
International Protection (IP) code	IPX2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
USB 2.0 ports quantity	4
Connectivity technology	Wired & Wireless
Media thickness	0.14 - 0.19 mm
Maximum roll diameter	105 mm
Storage temperature (T-T)	-5 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 75 %
Cables included	AC
Quantity per pack	1 pc(s)
Languages support	Multi

Weight and Dimensions

Depth	225 mm
Width	132 mm
Height	180 mm
Weight	3000 g
