SATO FX3-LX Driver Manual

28
Installing the printer driver for second and later printers 1.3.4
When using multiple printers, you need to install printer drivers for each printer.
When connected via USB
Power off the printer and connect the printer to the computer. 1.
Power on the printer. 2.
The Plug and Play feature runs and the printer driver is automatically installed.
If necessary, change the printer name. 3.
Note:
You cannot install the printer driver as port and printer names that have already been created. Change the
name(s).
When connected via a LAN or wireless LAN
Use the same procedure as the first printer to install the driver.
Double-click PrnInst.exe. 1.
To finish installing the driver, follow the same procedure as the first printer. 2.
Note:
You cannot install the printer driver as port and printer names that have already been created. Change the
name(s).
When connected via Bluetooth
Use the same procedure as the first printer to install the driver.
Pair the printer with the computer. 1.
Double-click PrnInst.exe. 2.
To finish installing the driver, follow the same procedure as the first printer. 3.
Note:
You cannot install the printer driver as port and printer names that have already been created. Change the
name(s).

SATO FX3-LX Specifications

General

Cutter	Yes
Certification	EN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodes	AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID module	No
Maximum resolution	- DPI
Maximum print height	500 mm
Maximum printing width	80 mm
Battery voltage	14.4 V
AC input voltage	100 - 240 V
Battery capacity	1950 mAh
AC input frequency	50 / 60 Hz
Suitable for use in country/location	Europe
Sustainability certificates	ENERGY STAR
Display	LCD
Control type	Touch
Product color	White
Display diagonal	7 \
Display resolution	480 x 800 pixels
International Protection (IP) code	IPX2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
USB 2.0 ports quantity	4
Connectivity technology	Wired & Wireless
Media thickness	0.14 - 0.19 mm
Maximum roll diameter	105 mm
Storage temperature (T-T)	-5 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 75 %
Cables included	AC
Quantity per pack	1 pc(s)
Languages support	Multi

Weight and Dimensions

Depth	225 mm
Width	132 mm
Height	180 mm
Weight	3000 g
