2.2.3 Description of display
Alarms
(1) Status field for physiological alarms
(2) Status field for technical alarms
Curve field
(3) 1 or 3 channel leads display. With enter display 1 or 3 leads, with
up/down select the following/previous lead/lead group.
System status field
(4) System status field
(5) Symbol for battery operation.
(6) Loudness (3-step) for alarm- and QRS-sound. Adjust with left button.
(7) Symbol of the selected patient type.
Blood pressure
(8) < 0:12 A = remaining time (h/min) to the next automatic blood pressure meas-
urement.
> 0:12 = Time since the last manual blood pressure measurement
Remark: During blood pressure measuring the actual system pressure in mmHg
will be displayed.
Measurement field
(9) Various displayed values e.g. HR, Sp0
2
, IBP, CO
2
, RRi, temperature.
HR
/ min
60
98
60
SpO
2
PP
/ min
%
10
RRi
/ min
R
P
P
I
II
III
11 :04 28-10-04
127/77
(100)
36.8
T
1
°C
Alarm HR Low ECG lead off
I
I
II
III
I,II, …
aVR, III,...
>0:12
1
2
3
56
78
PM ON
SYS/DIA
(MAP)
4
PM detection
RRi Alarm
switch off
NIBP
mmHg
<0:12A
9
