Appendix 7
Operating Instruction Settings menu 7.1
Art. no.: 2.510474 rev.: d
ARGUS LCM/PLUS
7Appendix
7.1 Settings menu
7.1.1 Main menu
Bold marked values are factory settings.
Main menu Parameter Values
ECG Display sensitivity 5/10/20/40 mm/mV
a
ECG - Filter
a. Diagnostic (Hardware filter): High/low-pass: hp = 0.05 Hz, lp = 150 Hz for LCMplus and LCMbasic SN < 1000
Monitoring 1 (Hardware filter): High/low-pass: hp = 0.5 Hz, lp = 40 Hz for LCMbasic SN > 1000
Monitoring 2 (Hard & Software):Hardware see above, SW
hp
= 0.6 Hz, SW
lp
= 35 Hz
Artefact (Hard- and Software): Hardware see above, SW
hp
= 2.4 Hz, SW
lp
= 20 Hz
a
Diagnostic/ Monitoring 1 / Monitoring 2 / Artefact
QRS beep source Off/ ECG/ SpO
2
Pacemaker Off /On (If pacemaker on, it is no RRi measuring possible)
RRi Alarm On /Off
Cable mode Automatic /3-/5-/10-or 3p electrodes
Mains filter Off/ 50 or 60 Hz
NIBP Initial pressure Adult 180, pediatric 150, neonatal 120 mmHg (0..300)
Autom. measuring Off/ On
Interval time 2/3/5/10/15/ 30/60 min
Deflation speed 5 (3..9)
SpO
2
suppression Off/ On
IBP Scale 0..300/200/100/50/30/Auto
Start IBP Calibration Function
CO
2
Flow Rate 200/120/90 ml/min (See chapter 7.4 for more details)
O
2
-Compensation Off/ On (Off = O
2
≤ 60% / On = O
2
> 60%)
N
2
O Compensation Off/ On (Off = 0% N
2
O /On = ≥ 12%)
Desflurane compensation Off/ On (On = Desflurane ≥ 12%)
Steam compensation Off/ On
BTPS compensation Off/ On
Zero point cal. date ddmmjj
Two point cal. date ddmmjj
Start zero Point Calibration Function
Start two-Point Calibration Function
System Patient Adult/Pediatric/Neonatal
Date ddmmjj
Time hhmm
About Device info see section 7.7.2
