Maintenance 5
Operating Instruction Trouble shooting 5.6
Art. no.: 2.510474 rev.: d
ARGUS LCM/PLUS
5.6.1 Accessories and disposables
Your local representative stocks all the disposables and accessories available for the
Argus LCM. A full list of all SCHILLER representatives can be found on the SCHILL-
ER website (www.schiller.ch). In case of difficulty, contact our head office in Switzer-
land. Our staff will be pleased to help process your order or to provide any details for
all SCHILLER products.
IBP Artefact • Loose sensor contact
• A manipulation at the sensor,
such as rinsing, has caused vari-
ation peaks ± 150 mmHg
« Inspect the sensor and cable connection.
« After rinsing, calibrate the sensor.
IBP wrong value • Constant pressure ( ± 30 mmHg)
during calibration
« Check tube system, sensor and ventil. Set the sensor to
ambient pressure
« Calibrate the sensor.
Paper insert • Paper finished « Insert new paper.
Check paper • Paper jammed « Check the paper.
Battery low • Battery capacity too low « Connect the device to the mains and recharge the bat-
tery.
Respiration curve field is not
shown
• Pacemaker is On and respiration
source is ECG
« Set respiration source to CO
2
or pacemaker to Off.
Respiration curve is not dis-
played
• HF ECG cable connected « Connect standard ECG cable
No QRS sound • Setup QRS source « Set QRS source to SpO
2
or ECG
Pacemaker pulse is not dis-
played
• The pacemaker impulse will be
filtered by the HF protection in
the ECG cable.
« Connect standard ECG cable
V Always use SCHILLER replacement parts and disposables, or products ap-
proved by SCHILLER. Failure to do so may endanger life and invalidate the
guarantee.
Alarm Cause Remedy
Table page 2 of 2
