4 Technical Data
EN-US · 30.30.00.00424 · 07 · 10/23 15 / 86
Parameter Symbol Limit values Unit Comment
Voltage of signal input (PNP) U
IH
15 — U
A/SA
V
DC
In reference to Gnd
A/
SA
Voltage of signal input (NPN) U
IL
0 — 9 V
DC
In reference to U
A/SA
Current of signal input (PNP) I
IH
— 5 — mA —
Current of signal input (NPN) I
IL
— -5 — mA —
Response time of signal inputs t
I
— 3 — ms —
Response time of signal out-
puts
t
O
1 — 200 ms Adjustable
1) The power supply must correspond to the regulations in accordance with EN60204 (protected extra-low
voltage). The signal inputs and outputs are all protected against reverse polarity.
2) Plus the output currents
3) The signal output is protected against short circuits. However, the signal output is not protected
against overloading. Constant load currents > 0.15A may lead to impermissible heating and therefore the
destruction of the ejector.
4) Mean value
5) Average value; pulse currents of 140 mA and 30 milliseconds possible when switching the valves.
4.4Factory Settings
The following table shows the factory settings of the ejector:
Code Parameter Value of the factory setting
X-1
Limit value H1 750mbar
h-1
Hysteresis value h1 150mbar
X-2
Limit value H2 550mbar
h-2
Hysteresis value h2 10mbar
tbL
Blow off time 0.2s
ctr
Control
Activated = on
dc5
Permanent suction
Deactivated = off
t-1
Evacuation time 2s
-L-
Leakage value 250mbar/s
bLo
Blow off function
Externally controlled blow off = -E-
uni
Vacuum unit
Vacuum unit in mbar = -bA
tYP
Signal type
PNP switching = PnP
dLY
Switch-off delay 10ms
dPY
Display rotation
Standard = 5td
Eco
Eco mode
Deactivated = oFF
Pin
PIN
User-defined 000
o-2
Signal output “Normally open” contact = no
The production setup profiles P-1 to P-3 are factory-set to have the exact same data set as the default
data set P-0.
