Schmalz SCPSi - Spare and Wearing Parts

15 Spare and Wearing Parts
68 / 86 EN-US · 30.30.00.00424 · 07 · 10/23
15Spare and Wearing Parts
Maintenance work may only be carried out by qualified personnel.
4 WARNING!Risk of injury due to improper maintenance! After performing any maintenance or re-
pair work, check that the system is functioning correctly, particularly the safety features.
NOTE
Incorrect maintenance work
Damage to the ejector!
4 Always switch off the supply voltage before carrying out maintenance work.
4 Secure it so that it cannot be switched back on.
4 Ejector must be operated only with a silencer and press-in screens.
The following list contains the most important spare and wearing parts.
Part no. Designation Legend
10.02.02.04141 Silencer insert Wearing part
10.02.02.04404 Screen Spare part
10.02.02.04152 Insulating plate Wearing part
10.02.02.04737 Ejector wear part set for 1-stage variant Wearing part
10.02.02.04738 Ejector wear part set for 2-stage variant Wearing part
When tightening the fastening screws on the silencer module, observe a maximum tightening torque of
0.5Nm.
When you replace the silencer insert, we recommend that you also replace the insulating
plate.
