19 Attachment
72 / 86 EN-US · 30.30.00.00424 · 07 · 10/23
19Attachment
See also
2 SCPSi_V2 Data Dictionary 21.10.01.00065_02 2014-08-29.PDF [}74]
19.1Overview of the Display Codes
Code Parameter Comment
x-1
Limit value H1 Switch-off value for air-saving function/control
h-1
Hysteresis value h1 Hysteresis of control
x-2
Limit value H2 Switch-on value of the “Part Present” signal output (when the NO
output is configured)
h-2
Hysteresis value h2 Hysteresis of “Part Present” check signal output
tbL
Blow off time Set the blow off time for time-controlled blow off
CAL
Zero-point adjustment Calibrating the vacuum sensor
cc1
Total counter 1 Counter for suction cycles (“suction” signal input)
cc2
Total counter 2 Counter for valve switching frequency
5oc
Software function Displays the current software version
Art
Part number Displays the part number of the ejector
5nr
Serial number Displays the serial number of the ejector
Ctr
Energy-saving function
(control)
Setting the control function
on5
Control function on
with leakage monitor-
ing
Control with leak monitoring active
dc5
Deactivate auto. con-
trol shutoff
Suppresses the automatic valve protection function when set to
YE5.
Cannot be activated when Ctr = off .
t-1
Evacuation time Set the maximum permitted evacuation time
-L-
Leakage value Set the maximum permitted leakage
bLo
Blow off function Menu for configuring the blow off function
-E-
“External” blow off Selection of externally controlled blow off
J-t
“Internal” blow off Select internally controlled blow off (triggered internally, time-ad-
justable)
E-t
“External time-con-
trolled” blow off
Selection of externally controlled blow off (triggered externally;
time-adjustable)
o-2
Signal output Menu for configuring the signal output
no
Normally open contact Setting of the signal output as a normally open contact
nc
Normally closed contact Setting of the signal output as a normally closed contact
tYP
Signal type Menu for configuration of the signal type (NPN/PNP)
PnP
PNP signal type All input and output signals switch according to PNP (input / out-
put on = 24V)
nPn
NPN signal type All input and output signals switch according to NPN (input / out-
put on = 0V)
uni
Vacuum unit Setting the vacuum unit
-bA
Vacuum level in mbar The displayed vacuum level is shown in mbar.
-PA
Vacuum level in kPa The displayed vacuum level is shown in kPa.
