Schmalz SCPSi - Dimensions

4 Technical Data
EN-US · 30.30.00.00424 · 07 · 10/23 17 / 86
4.6Dimensions
Version without power blow-off
B B1 d
(d1)
1
(d2)
1
d3 G1 G2 G3 H H2 H3
18 18.6 4.4 6 / 8 6 / 8 2.6 1/8"
inter-
nal
threa
d
1/8"
inter-
nal
threa
d
M12x
1 ex-
ternal
threa
d
99 40.8 47.5
H4 H5 L L1 L2 L3 L4 L5 X1 X2 Y1 Y2
16.5 5.5 83.8 105 91.5 22 29.5 83.8 36.9 16 12 12
