5 Operating and Menu Concept
EN-US · 30.30.00.00424 · 07 · 10/23 23 / 86
5.2.2Changing the Parameters of the Main Menu
1. Open the main menu by pressing the MENU button.
2. Use the UP or DOWN button to select the desired adjustable parameter.
3. Confirm the selection with the MENU button.
4. Use the UP or DOWN button to set the value of the parameter.
5. To save and exit the menu, press and hold the MENU button for at least 2 seconds.
ð The displayed value flashes to confirm.
The factory settings for the parameters are listed in the Technical Data section.
5.3Configuration Menu
An extended configuration menu is available for applications with special requirements.
5.3.1Functions in the Configuration Menu
The following table shows an overview of the display codes in the configuration menu:
Display
code
Parameter Possible settings Explanation
ctr
Air saving func-
tion
on
oFF
on5
Control active
Control inactive
Valve protection function active (max. permissi-
ble leakage is monitored)
dC5
Deactivate auto.
control shutoff
on
oFF
Suppresses the automatic valve protection func-
tion when set to YE5.
Cannot be activated when Ctr = off .
t-1
Max. permissi-
ble evacuation
time
Configurable be-
tween 0.01 and
9.99s in 0.01 incre-
ments
off
Permissible evacuation time; evaluation in IO-
Link only
No monitoring
-L-
Max. permissi-
ble leakage
Values from 0 to
999mbar/s can be
configured in
1mbar/s increments
Menu item only displayed when ctr = On5
Unit: millibar per second
This value is used for onS and CM warnings. The
adjustable leakage value can be used to judge
the quality of the suction process. Evaluation in
IO-Link only.
bLo
Blow off func-
tion
-E-
1-t
E-t
Externally controlled
Internally controlled (triggered internally, time
can be set)
Externally controlled (triggered externally, time
can be set)
o-2
Signal output 2
no
nc
Configure output 2, “Part Present” check
for normally open
for normally closed
tYP
Signal type
PnP
nPn
Define signal type for inputs and outputs
Signal type PNP, input/output on = 24V
Signal type NPN, input/output on = 0V
dLY
H2 switching
signal delay
Values: 10, 50,
200 and oFF
Delays the switching signals X1 and X2
Unit: milliseconds
