5 Operating and Menu Concept
24 / 86 EN-US · 30.30.00.00424 · 07 · 10/23
Display
code
Parameter Possible settings Explanation
uni
Vacuum unit
-bA
-ix
-PA
Define the displayed vacuum unit
Vacuum level in mbar
Vacuum level in inHg
Vacuum level in kPa
dPY
Display rotation
5td
Red
Display configuration
Standard
Rotated 180°
Eco
Display in Eco
mode
oFF
on
Configure the display
Eco mode is deactivated – the display remains
on
ECO mode is activated – the display switches off
Pin
PIN
Value from 001 to
999
Specify the PIN, lock the menus
If the PIN is 000, then the device is not locked.
rE5
Reset
YES
Set all parameter values to factory settings.
5.3.2Changing the Parameters of the Configuration Menu
1. Open the configuration menu by pressing the MENU button for more than 3 seconds.
ð During activation, [-C-] appears.
2. Use the UP or DOWN button to select the desired adjustable parameter.
3. Confirm the selection with the MENU button.
4. Use the UP or DOWN button to set the value of the parameter.
5. To save and exit the menu, press and hold the MENU button for at least 2 seconds.
ð The displayed value flashes to confirm.
The factory settings for the parameters are listed in the Technical Data section.
5.4System Menu
A special menu is available for reading out system data such as counters, the software version, part num-
bers and serial numbers.
5.4.1Functions in the System Menu
Display code Parameter Explanation
cc1
Counter 1 Suction cycles
cc2
Counter 2 Number of valve switches
5oC
Software function Software on the internal controller
Art
Part number Format of the part no., example: 10.02.02.00383
5nr
Serial number Provides information about the production period
