IO-Link Data Dictionary SCPSi series
21.10.01.00065/02 29.08.2014
J. Schmalz GmbH
Aacher Straße 29, D 72293 Glatten
Tel.: +49(0)7443/2403-0
Fax: +49(0)7443/2403-259
info@schmalz.de
IO-Link Version 1.0 (legacy mode)
234 (0x00EA)
100242 (0x018792)
Yes
38.4 kBd (COM2)
3.0 ms
1 byte
1 byte
0 ro IO-Link V1.1, V1.0 Vacuum is over H2 & not yet under H2-h2
1 ro IO-Link V1.1, V1.0 Vacuum is over H1 & not yet under H1-h1
2 ro - unused
3 ro IO-Link V1.1, V1.0 Acknowledge that the Autoset function has been completed
4 ro IO-Link V1.1 only
Acknowledge that EPC values 1 and 2 have been switched according to
EPC-Select:
0 - EPC-Select = 00
1 - otherwise
5 ro IO-Link V1.1, V1.0 Device is working optimally
6 ro IO-Link V1.1, V1.0 Device is working but there are warnings
7 ro IO-Link V1.1, V1.0 Device is not working properly, there are errors
7…0 ro IO-Link V1.1 only
EPC value 1 (byte)
Holds 8bit value as selected by EPC-Select
(see PD Out Byte 0)
7…0 ro IO-Link V1.1 only
7…0 ro IO-Link V1.1 only
IO-Link Version 1.1
234 (0x00EA)
38.4 kBd (COM2)
3.5 ms
4 byte
Access
EPC value 2 (word)
Holds 16bit value as selected by EPC-Select
(see PD Out Byte 0)
Device status - yellow
Device status - red
CM-Autoset acknowledged
-
Signal H1 (automatic air saving function)
EPC value 2, low-byte
Name Bits
PD In Byte 0
Processdata input
Availability Remark
Vendor ID
Process Data In
Processdata output
Baudrate
Minimum cycle time
EPC-Select acknowledged
PD In Byte 3
SIO-Mode
PD In Byte 1 EPC value 1
PD In Byte 2
2 byte
Device status - green
EPC value 2, high-byte
Signal H2 (part present)
IO-Link Implementation
Process Data
Yes
Device ID 100243 (0x018793)
J. Schmalz GmbH
1 of 11 SCPSi Data Dictionary
