IO-Link Data Dictionary SCPSi series
21.10.01.00065/02 29.08.2014
J. Schmalz GmbH
Aacher Straße 29, D 72293 Glatten
Tel.: +49(0)7443/2403-0
Fax: +49(0)7443/2403-259
info@schmalz.de
0 wo IO-Link V1.1, V1.0 Vacuum on/off
1 wo IO-Link V1.1, V1.0 Activate Blow-off
2 wo IO-Link V1.1, V1.0
Vacuum on/off with continuous suction disabled
(regardless of dCS parameter)
3 wo IO-Link V1.1, V1.0 Perform CM Autoset function and save EPC data in buffer
5..4 wo IO-Link V1.1 only
Select the function of EPC values 1 and 2 in PD In
(content is 2 bit binary coded integer)
0:
EPC value 1 = Input pressure (0.1 bar)
EPC value 2 = System vacuum (1 mbar)
1:
EPC value 1 = CM-Warnings (see ISDU 146 for bit definitions)
EPC value 2 = Evacuation time t1 (1 msec)
2:
EPC value 1 = Leakage of last suction cycle (1 mbar/sec)
EPC value 2 = Last measured free-flow vacuum (1 mbar)
3:
EPC value 1 = Primary supply voltage (0.1 Volt)
EPC value 2 = Air consumption of last suction cycle (0.1 NL)
7..6 wo IO-Link V1.1, V1.0
Select Production Profile
(content is 2-bit binary coded integer)
0: Activate Production Setup Profile P0
1: Activate Production Setup Profile P1
2: Activate Production Setup Profile P2
3: Activate Production Setup Profile P3
7…0 wo IO-Link V1.1 only Pressure value from external sensor (unit: 0.1 bar)
PD Out Byte 0
Input pressure
Name
Vacuum
Profile-Set
Availability RemarkProcess Data Out Bits
PD Out Byte 1
CM Autoset
Access
Blow-off
EPC-Select
Vacuum with forced control
J. Schmalz GmbH
2 of 11 SCPSi Data Dictionary
