Revision: 3.0 Page 51 of 70
Measurement ranges DIP Switch [S1]
Humidity ranges
Range
3
4
5
6
7
8
Relative humidity
0 % ... 100 %
OFF
OFF
OFF
OFF
OFF
OFF
Absolute himudity
0 g/m³ … 30g/m³
ON
OFF
OFF
OFF
N/A
N/A
0 g/m³ … 50g/m³
ON
ON
OFF
OFF
N/A
N/A
0 g/m³ … 80g/m³
ON
ON
ON
OFF
N/A
N/A
Mix ratio
0 g/kg … 30g/kg
OFF
OFF
OFF
ON
N/A
N/A
0 g/kg … 50g/kg
OFF
OFF
ON
ON
N/A
N/A
0 g/kg … 80g/kg
OFF
ON
ON
ON
N/A
N/A
Dew point
0°C … +50°C
OFF
ON
ON
OFF
N/A
N/A
-50°C … +100°C
ON
OFF
OFF
ON
N/A
N/A
-20°C … +80°C
OFF
ON
OFF
ON
N/A
N/A
Enthalpy
0 kj/kg … 85kj/kg
ON
ON
ON
ON
N/A
N/A
Electrical connection
Pin
Typ U [0...10 V]
Typ I [4...20 mA]
1
temp
-
2
r.h.
-
3
poti act [opt]
temp
4
-
r.h.
5
poti pas. [opt]
6
poti pas. [opt]
7
V+
8
GND
9
relay NC [opt]
10
relay C [opt]
11
relay NO [opt]
12
sensor °C pas. [opt]
13
sensor °C pas. [opt]
R1
temp. adjustment
S3
polarity R3
