The adapters are delivered already configured and only have to be wired to the SchwankControl
control and the BMS system available at the customer’s premises. This requires an IP that is within the
subnet range of the customer.
If we do not know the customer IP on delivery, we burn a standard IP, which is glued to the
corresponding adapter. This IP must be adapted to the customer if necessary. This requires the
configuration software and the configuration files on the FTP server [see introductory remarks in section
12].
11.4.1. Wiring for converter
MODBUS RTU > MODBUS TCP or BACNet Ip
Comes with the adapter in printed form
