Schwank Control Touch - 3 Technical Specifications

Revision: 3.0 Page 6 of 71
3. Technical specifications
Type
Value
Unit
Supply voltage
230 /- 5% [1~, N, PE]
V
Max. current consumption
6.3
A
Mains frequency
50 / 60
Hz
Protection class
IP 65
Ambient temperature
0...40
°C
Max. relative humidity
80
%
Mounting
Wall mounting
CE Conformity
yes
Room temperature sensor, RTS
Schwank Part No. 4065-2071
NTC 10
kΩ
Outdoor temperature sensor, OTS
Schwank Part No. 4065-2081
NTC 10
kΩ
Operation and display - touch display
4.3
480 x 272
Inch
Pixel
Dimensions [W x H x D]
260 x 190 x 170
mm
Weight
1.1
kg
Table 1: Technical specifications
Network and buses
For setting up larger heating systems, up to eight control units with a maximum of two operating units can be
connected via CAN bus. Each operating unit allows independent operation of all control units located on the
bus.
CAN 2.0B standard baud rate 125 kBit
The control unit is equipped with two RS485 interfaces for networking Schwank automatic burner control units
and for integrating the SchwankControl into building control systems.
The operating unit can also be connected to a LAN. The operating unit can be operated via a web interface
using other computers in the network.
Ethernet 10/100 Mbit
