Configuration [Expert]
 Heater types:
 Zone1: Modulating luminous heater
 Zone2: Deactivated
 Zone3: Deactivated
 Zone4: Deactivated
 Relay outputs:
 Relay1: Zone1 heater on/off
 Relay2: Zone1 heater stage
 Relay3: Zone1 fan on/off
 Relay 4-6: Deactivated
 Digital inputs:
 1-6: No function
 Heater Modbus addresses:
 No assignment at all
 More:
 Release contact: Opening
 Gas meter: 0.01 m³/pulse
 Heating time extension: 60min
 Service interval: 12 months
 Setpoint temperature display: Yes
 Modbus slave addr: auto
 Temp.time prog. Off: Night
 Temp.time prog. On: Day
 Water meter: 1l/pulse
 Hybrid switch-off: 90°C
 Fan error display: 10s
