SEL-321/321-1 Instruction Manual
=>>CONTROL 5 <ENTER>
CONTROL 5 <ENTER>CONTROL 5 <ENTER>
CONTROL 5 <ENTER>
CONTROL RB5: PRB 5 3 <ENTER>
PRB 5 3 <ENTER>PRB 5 3 <ENTER>
PRB 5 3 <ENTER>
=>>
Table 3.3: SEL-321-1 Relay CONTROL Subcommands
Subcommand Description
SRB n Set Remote Bit n
CRB n Clear Remote Bit n
PRB n t Pulse Remote Bit n for t seconds
t = 1 if not otherwise specified
Note: n must match the CONTROL command bit number.
COPY m n
The COPY command copies settings and logic from setting Group m to Group n (m and n equal
any combination of 1, 2, 3, 4, 5, or 6). Usually, there are few setting or logic differences between
groups. If you enter one setting group with the SET command, you can copy it to other groups
with the COPY command. Use SET to modify copied setting groups.
If you copy settings to a group for which event reports exist, those event reports will show
"SETTINGS CHANGED SINCE EVENT" when recalled with the EVE command. The ALARM
output contact closes momentarily when you change settings in an active setting group.
=>>COPY 4 6 <ENTER>
COPY 4 6 <ENTER>COPY 4 6 <ENTER>
COPY 4 6 <ENTER>
COPY 4 to 6
Are you sure (Y/N) ? Y <ENTER>
Y <ENTER>Y <ENTER>
Y <ENTER>
Please wait...
Settings copied
=>>
DATE
The DATE command displays the date stored by the internal calendar/clock. Set the date by
typing DATE mm/dd/yy <ENTER>.
Set the date to February 1, 1993, by entering:
=>DATE 02/01/93 <ENTER>
DATE 02/01/93 <ENTER>DATE 02/01/93 <ENTER>
DATE 02/01/93 <ENTER>
02/01/93
=>
The relay sets and displays the new date.
