Press RETURN to continue
OUT12 =NA
OUT13 =NA
OUT14 =NA
OUT15 =NA
TMB1 =NA
TMB2 =NA
TMB3 =NA
TMB4 =NA
TMB5 =NA
TMB6 =NA
TMB7 =NA
TMB8 =NA
=>>
SET P
Use SET P to change settings for the active communications port; Table 3.11 explains the
settings. To go to the settings for a particular port, enter the port number (1 - 3) after SET P. The
following display shows an example for Port 1. To edit a particular setting, enter the setting label
after the port number. For example, enter SET P 3 AUTO (enter parameters in any order) to edit
the AUTO setting for Port 3. The following display shows setting prompts for Port 1. You can
also make settings from the front panel (see Setting Changes via Front Panel under LCD
Functions and Front-Panel Commands).
Note: FAST_OP setting included in SEL-321-1 Relay only.
=>>SET P
SET PSET P
SET P 1 <ENTER>
1 <ENTER> 1 <ENTER>
1 <ENTER>
PROTOCOL (SEL,LMD,MB,MB8) PROTOCOL= SEL ?
BAUD RATE (300-38400) SPEED = 2400 ?
DATA BITS (6,7,8) DATA_BITS= 8 ?
PARITY (O,E,N) PARITY= N ?
STOP BITS (1,2) STOP = 1 ?
TIMEOUT (0-30 min) TIMEOUT= 0 ?
SEND AUTO MESSAGES TO PORT (Y,N) AUTO = N ?
ENABLE HARDWARE HANDSHAKING (Y,N,MBT) RTS_CTS= N ?
FAST OPERATE ENABLE (Y,N) FAST_OP= Y ?
PORT:1 XOFF RECEIVED:N XOFF SENT:N
PROTOCOL= SEL
SPEED = 2400 DATA_BITS= 8 PARITY= N STOP = 1
TIMEOUT= 0 AUTO = Y RTS_CTS= N FAST_OP= N
Save changes (Y/N) ? Y <ENTER>
Y <ENTER>Y <ENTER>
Y <ENTER>
Settings saved
=>>
Table 3.11: SET P Fail Message
Message Comment
MB only allowed on a single port. Port 1 is
already using MB.
MB only allowed on a single port. Port 2 is
already using MB.
The MIRRORED BITS protocol can only be in
use on a single port.
The M
IRRORED BITS protocol can only be in
use on a single port.
